The Unresolved Need for Dependable Guarantees on Security, Sovereignty, and Trust in Data Ecosystems

Introduction

Data-driven analyses and business models are invaluable pillars for modern industries and societies alike. Their importance will increase with growing demands, requiring more complex and globally distributed operations and sophisticated collaborations to improve the status quo [1]. Data ecosystems provide the foundation for such data-driven analyses and business models as they center around automating data exchanges and value creation based on vast and heterogeneous data sources from various stakeholders [2]. Data ecosystems also create value beyond business, e.g., as a platform for research data lineage and exchange or to organize health records. Added value can be created by, for instance, improving algorithms underlying existing analytics or extracting new insights of previously recorded data [3]. Crucially, this process involves the integration of distributed data sources owned by different stakeholders. Here, data ecosystem initiatives such as International Data Spaces (IDS) [4] and GAIA-X [5] aim to provide a trustworthy environment for the discovery, sharing, and processing of available data, irrespective of specific domains. Various related work [6][7][8] complements these efforts, and selected deployed systems, such as distributed health data platforms [9][10], can already be considered early instantiations of data ecosystems.

However, the data prosperity promised by transitioning toward data ecosystems and their implied large-scale data exchanges among different stakeholders increases data confidentiality and privacy risks. Aggravatingly, current efforts to establish the necessary trust among these stakeholders heavily rely on organizational agreements and processes instead of technical or cryptographic measures to provide security guarantees [4][11]. These agreements frequently include a certification process for stakeholders prior to admission [12][13]. For instance, the IDS certification process asserts that participants use audited software and develop so-called “defense-in-depth” protection strategies that comprise redundant layers of (organizational) security measures for protection [4]. Participants receive no tangible additional security guarantees beyond this ahead-of-time certification. Most notably, they cannot verify that other participants handle their data as intended. Here, the lack of stronger guarantees effectively undermines data sovereignty and trust between participating stakeholders as soon as they start sharing their data.

We thus argue that one needs to make a fine distinction between organizational security measures that depend on trust in other stakeholders, and dependable guarantees that instead rely on technical or organizational means and require trust in these means, but not in another stakeholder’s honesty. Within this paper, we establish that current data ecosystems frequently focus on the former, which might be sufficient for certain scenarios. However, we also show that there are valid use cases, such that data ecosystems should additionally consider dependable guarantees that are as of now, not widely implemented.

The notion of dependability is commonly used in systems engineering to express the absence of failures; however, according to Anderson [14] there is also a security aspect: He considers “assurance” a critical component of dependability, which refers to the amount of reliance one can put in specific (security) mechanisms. According to that notion, we understand a dependable guarantee in the context of data ecosystems as a guarantee not building upon trust in another participant’s or the platform’s honesty regarding data handling. Thus, dependable guarantees enable the enforcement of e.g., policies between otherwise loosely-coupled and distrustful stakeholders, thereby enhancing data sovereignty.

We acknowledge that besides data security multiple aspects contribute to data sovereignty, including legal and architectural decisions [15]. However, we argue that the notion of dependable guarantees for data security, as established in this work, is a prerequisite for dependable data sovereignty in data ecosystems. Specifically, remote participants must be assured that inside attackers pose no threat to their data sovereignty. Thus, in this paper, we extend our preliminary analysis of the need for dependable security guarantees to enhance data sovereignty in data ecosystems [16]. Specifically, we discuss implementation costs and limitations dependable guarantees would necessarily introduce. Moreover, we further underpin our claim by systematically mapping and analyzing previous works on data ecosystems and related use cases. Namely, this work makes three contributions:

• We provide an understanding of the trade-off between data ecosystems as a tool to facilitate collaboration on and the exchange of data and the impact dependable data sovereignty guarantees would imply.

• We analyze and discuss three important and diverse use cases for data ecosystems: medical data records, supply chains, and a smart city application. Our analysis highlights further privacy and security concerns that are unresolved by current proposals for data ecosystems.

• We systematically map 2135 academic works focusing on data ecosystems concerning their implemented security principles and find 262 considering security or trust, but only 12 works make technical or cryptographic contributions toward improving dependable data security, data sovereignty, or trust. Our security analysis of these works reveals that only three of these works provide dependable guarantees that withstand inside attackers.

The remainder of this paper is structured as follows: First, in Section Section 2, we establish a common notion of current data ecosystem approaches, their architecture, and recent efforts of related work in securing data ecosystems. Based on our analysis, we derive three central design questions guiding data ecosystem security in Section Section 3. We complement our analysis with an outlook of possible building blocks for fixing these issues in Section Section 4. In Section Section 5, we introduce three use cases concerning personal, economic, and governmental data security. Next, in Section Section 6, we map academic efforts to improve data system security with a focus toward dependable guarantees. We discuss potential future research directions in Section Section 7, before concluding this paper in Section Section 8.

##A Primer on Current Data Ecosystems and their Architectures {#sec:current-state}

To ensure a common understanding of the security and trust issues with today’s data ecosystems, we first briefly introduce data ecosystems and recapitulate the notion of data sovereignty and the role of typical participants in this context. Moreover, we give a short overview of data ecosystem initiatives focusing on their currently implemented security measures.

Overview

The need to share data with collaborators within specific sectors has been recognized in a variety of domains, including supply chains [17][18], public health [10][19], and mobility [20]. Here, on the one hand, data ecosystems aim to provide multi-sided platforms [2] that facilitate an automated data exchange following the FAIR principle [21], i.e., the offered data needs to be findable, accessible, interoperable, and reusable. On the other hand, today’s data ecosystems aim to equip data owners with fine-grained control over their data, including with whom and under what terms data may be shared. Enabling this fine-grained control is the foundation of data sovereignty [3]. The realization of fine-grained control over shareable FAIR date requires solving issues regarding organization [2], semantics and data quality [22], and interfacing [23], all of which are currently under active research.

So far, data ecosystems have primarily been seen as a means for exchanging data as required in emerging data markets and other use cases [3]. The paradigm of data ecosystems gradually emerged without a standard definition in mind, i.e., different accelerators of this paradigm came up with their own working definition of data ecosystems. Identifying this fragmented landscape of data ecosystem developments, Oliveira and Lóscio [24] reviewed concurrent definitions. They proposed a unified definition for data ecosystems based on their review. As a result, they define a data ecosystem as a combination of independently operated networks that produce and provide data, but also other assets, such as software or services [24]. Moreover, the authors highlight that such data ecosystems are self-regulated and driven by collaboration and competition between actors [24]. Extending this definition, we further emphasize that data ecosystems form platforms that have to define standard interfaces and rules to enable collaboration across independent networks. Accordingly, we consider entities that implement the interfaces and accept the rules defined by a given ecosystem data ecosystem as participants.

Likewise, the notion of data sovereignty, i.e., one of the fundamental motivations behind federated data ecosystems, currently lacks a clear and common definition [15]. If used in the context of data ecosystems, researchers generally agree that data sovereignty relates to the control and ownership of data items and the ability to specify, enforce, and trace specific claims on data [25][26][27][28]. Data sovereignty must not be confused with other types of notions of sovereignty, such as digital sovereignty or technical sovereignty [29]. Data ecosystems aim to fulfill these demands. Hence, this paper will focus on this aspect of data sovereignty as well as security and trust considerations connected to the enforcement of data sovereignty. Other aspects of data sovereignty, such as inclusive deliberation and the rights of data subjects [15], are as important as those mentioned above but require a societal solution in the first place.

Proposed Data Ecosystems and Current Initiatives

Several existing proposals shape the structure of data ecosystems. In the following, we introduce relevant approaches, both from theory and practice, that exemplify typical design decisions of data ecosystems.

Theoretical Work. To characterize data ecosystems, Azkan et al. [30] derive a morphology along the dimensions service ecosystem, service platform, and value co-creation. The authors emphasize data as a core resource and state that such systems are only sustainable if providers are intrinsically motivated to share data, typically to their own benefit. Gelhaar et al. [22] pick up the aspect of value creation and additionally emphasize trust between participants, a central problem of data ecosystems. Here, Zrenner et al. [7] derive an architecture for distributed usage control in business ecosystems from a use case in car manufacturing. Based on requirements such as fast load time, compatibility with existing systems, and transparency, the authors discuss an architectural solution for usage control [7]. Several other works consider data ecosystems tailored to specific needs, such as open data [31], financial data [32], or to describe the necessary data acquisition framework for machine learning tasks [33], that conceptually have a different focus, i.e., do not emphasize the distributed platform aspect, but consider data quality, quantity, and availability.

Practical Initiatives. Superseding a previously rather tedious bilateral exchange, the goal of initiatives like the International Data Spaces (IDS) [2][3][34], GAIA-X [5][23], Data Sharing Coalition [35], IHAN [36], FIWARE [37], CEF [38], or BDVA [39] is to establish a universal platform to regulate transactions regarding that exchange. The EU or federal offices fund such initiatives, facilitating a top-down approach toward establishing a common data platform [40]. This support recognizes the benefits of shared data, such as demonstrated by several recent efforts to combine previously distributed data silos [41].

Selected initiatives rather bundle forces toward adopting data ecosystems in general (Data Sharing Coalition, CEF, BDVA), while IHAN, for instance, is in an early stage, without publicly released technical documentation so far. Out of the named initiatives, IDS [4], GAIA-X [5], and FIWARE [42] have released technical documentation that enables a more profound analysis concerning what data security and trust measures are implemented in the respective proposals. Specifically, IDS and GAIA-X work toward a standard interface to locate and access data and provide an organizational context, including identification, admission, and certification of participants [23]. Thus, in the remainder of this paper, we primarily study these general-purpose initiatives. While IDS aims to provide a framework for data spaces to be built quickly, e.g., targeting a specific domain with coherent participants, GAIA-X plans to establish a single central cross-domain platform [23]. Moving toward domain-specific concepts, initial projects such as CATENA-X [43], an initiative inside the automotive domain, are picking up their ideas, while established platforms such as FIWARE [37], a framework to connect smart devices, start to provide compatible interfaces [44].

Key Aspects of Data Ecosystem Architectures

Despite their slightly different scopes, IDS and GAIA-X share a similar architecture. Thus, we analyze both initiatives together as a blueprint for data ecosystem implementations. To organize data exchange, data ecosystems commonly assign different roles to participants. Figure Figure 1 shows the overall scenario we are considering together with the main participants. Here, a single data exchange is considered bilateral, such that we can suppose the following roles [4]: First, a data owner legally owns the data to be shared and is interested in enforcing their rights on the data if it is shared. Second, a data provider takes over the technical part of offering a dataset to be exchanged on behalf of the data owner. While a single entity certainly can take over both roles, i.e., host the infrastructure to provide their data, the providing entity does not formally own the data in certain situations. For instance, this situation is the case for electronic health records owned by patients, which typically do not provide the infrastructure on their own. On the receiving side, a data consumer requests and receives the data from the provider and passes it to a data user, who processes the exchanged data, e.g., by visualizing it. Again, the consumer might fulfill the data user role if both processes are co-located. For instance, GAIA-X does not separate the data consumer and data user [5]. However, we continue using both terms to separate the logical roles, as described above.

Due to the distribution of providers and consumers, data ecosystems operate as a federation of independent deployments that jointly form a decentralized system. Thereby, data owners can keep their sensitive datasets under their control until they actively decide to share them with selected participants. To this end, data ecosystems enable data sovereignty until a data-sharing decision has been made and data is transferred to the data consumer.

Trust. To keep sovereignty from ending at the point of data exchange, data ecosystems currently require a certification of participants. Hence, they ensure that all entities handling data adhere to a common baseline regarding data protection. Certification includes but is not limited to, defense-in-depth strategies and security event monitoring systems [45][46]. Specifically, the IDS initiative requires prior certification steps. It attests successful certification via a public key infrastructure, establishing a trusted identity layer [4][23]. Contrarily, GAIA-X does not target a specific certification but requires participants to provide a standardized self-description with claims checked before admission [23]. In both cases, the ecosystem equips participants with the means to identify each other and establishes a common ground for mutual trust decisions.

Based on the ecosystem-wide identity layer, data ecosystems can provide fine-granular access control to data and let data owners limit the target audience they are willing to share their data with. However, more than access control is required, as data sovereignty would end once data flow between participants occurred after access was granted. Usage control [47] could fill this gap by granting specific rights on data and enforcing certain duties to be adhered to when processing data. Such a policy could be the permission to use a dataset for one week, with the obligation to delete it after that time.

To implement usage control, IDS utilizes and extends ODRL [48], a W3C standardized policy language for digital rights management [4]. Thereby, ODRL enables data owners and platform operators to define and communicate access and usage terms in a standardized fashion. As the only means of enforcement of the specified policies, the data owner has to trust that the consuming party abides by the negotiated terms and can only rely on the certification of the consumer required to join as a participant. However, since the negotiated contracts might also involve monetary compensation, the consuming party has incentives to disobey negotiated terms, e.g., using data more often than requested, sourcing it for other purposes, or sharing it with other systems or third parties.

Legal Context. Providing an environment for data exchange, the IDS builds upon surrounding legal contracts to equip participants with the means to establish credibility with each other [12]. Specifically, such contracts regulate the terms of usage and the overall setting, e.g., regarding a monetary compensation [4] or a penalty for breach of contract. Contracts can be bilateral or multilateral but will typically not cover the entirety of data space participants [4]. Because of this narrow consideration of available participants, current legal constructs centering around data ecosystems severely limit how spontaneous data consumers can access relevant data. Data ecosystems such as IDS then plan to (automatically) negotiate a refined technical contract within negotiated legal agreements. This refined contract translates terms into machine-readable policies that grant specific permissions on the exchanged dataset and potential obligations [4].

Data Ecosystems in Related Work

Having established a common notion of data ecosystems, we now focus on notable recent research efforts concerning data ecosystems. Specifically, we provide an overview of fundamental research regarding the organization of data ecosystems, research efforts investigating the use cases that would benefit from data ecosystems, and works that apply technical security measures to facilitate data sharing efforts.

Fundamental Data Ecosystem Advancements. Oliveira and Lóscio survey and map the components data ecosystems typically comprise [24][49]. Furthermore, several works discuss requirements and possible ways toward implementing data ecosystems in general, i.e., independent of specific initiatives [2][3][7][22][23][50]. Another line of research investigates fundamental challenges faced when implementing (distributed) data-sharing systems. Mainly, these challenges include transparency requirements [51], addressing the potential lack of trust between participants [22][52][53], the need for creating a common semantic understanding among all participants [13], and governance as well as legal constraints [12][54][55][56]. More directly targeted to data ecosystems as they are defined in this work, research considers alternatives to the current IDS and GAIA-X initiatives. For instance, FIWARE [37][44] provides a platform to facilitate data exchange in an Internet of Things context and is related to CEF [38]. Furthermore, special-purpose data ecosystems are being considered, e.g., by the NFDI initiative [57], which focuses on improving the accessibility of research data. Finally, NFDI and FIWARE aim to implement IDS-compatible interfaces, hence working toward ecosystem compatibility.

Use Cases. Another critical aspect of research on data ecosystems revolves around the use cases they are particularly well-suited for. Other works have identified many relevant or desirable use cases in this regard. Among these use cases are the sharing of medical health records [9][10], personal data [58], data emerging in the Industrial Internet of Things [59][60], and data exchange across supply chains, such as in the automotive industry [17][43][61], that have unique requirements concerning data confidentiality, data volume, or long-term persistency. Further data sharing schemes do not specifically target data ecosystems but are conceptually similar, such as applications in medicine [11][19][62][63], for production technology [64][65], along supply chains [17], or in education [66]. We expect that additional domains will also start to investigate the benefits data ecosystems can provide for their use cases as well as for society in general.

Technical Solutions for Data Sharing. Detached from data ecosystems, other research successfully applied technical and especially cryptographic building blocks to tackle the general challenges of data sharing in more narrow scenarios. For instance, Huang et al. [67] propose a data-sharing scheme to later identify sources of data breaches based on oblivious transfers and embedded fingerprints. Moreover, a variety of work considers sharing data with cloud providers [68][69][70][71][72][73], which can be considered conceptually similar to data ecosystems with multiple stakeholders. Such work includes querying encrypted data [74], attribute- or identity-based encryption for access control [61][63][75][76], and distributed ledgers together with TEEs to enforce accountability and access control [77]. Then again, Bonatti et al. [78] identify correctness and completeness as desirable properties of transparency mechanisms in data sharing. These approaches to strengthen sovereignty guarantees apply to real-world use cases and seem translatable for use in data ecosystems. However, given that these technical solutions originate detached from data ecosystems, the question arises to which end such solutions are already considered.

Security and Trust in Data Ecosystems. Schäfer et al. [79] identify suitable trust-enhancing technologies from expert interviews, including homomorphic encryption and trusted execution technology. Considering data markets in a more general sense, Liang et al. [80] survey digital rights management for privacy-preserving data trading, such as watermarking and software-based methods. Likewise, Garrido et al. [81] review privacy-enhancing technologies in the context of IoT data markets and identify handling copied data and multi-hop enforcement as problems not sufficiently covered in related work. Both of these surveys focus on data markets in general but do not specifically consider federated platforms with their unique (and challenging) threat model. To the best of our knowledge, no other related work systematically reviews the trust assumptions or security of federated data ecosystems, platforms, or markets.

Summary

While still under active research, academia, and large-scale initiatives shape the notion of data ecosystems as a means to simplify data exchange for value co-creation with data sovereignty as a key principle governing design decisions. They provide a common, distributed architecture that specifies interfaces and protocols and often also imply a certain legislative framework to establish trust, irrespective of the use case and domain at hand.

Data Ecosystems Need Dependable Guarantees

Based on the data ecosystems introduced in Section Section 2.2 to Section 2.4, we now critically review the design decisions of security mechanisms implemented in these data ecosystems. As, for instance, the EU facilitates establishing these platforms [40], we consider them relevant and worth studying concerning their dependable guarantees. Specifically, recent regulatory efforts set strict rules on how data may flow across organizational borders, raising, for instance, the need for fine-grained control [82]. To this end, data ecosystems are only sustainable if stakeholders are willing to participate by providing and consuming data actively.

At the same time, the current way of agreeing on terms for data exchange and usage incentivizes data-consuming parties to ignore these terms. Such behavior hurts data owners as they lose adequate compensation for the value of the data they provide and questions whether data ecosystems are adequate to exchange data subject to privacy regulation. Consequently, data owners might restrict their data-sharing efforts or leave the data ecosystem entirely. Hence, data ecosystems that plan to address these use cases need dependable guarantees, such as cryptographically enforceable guarantees and verifiable continual security monitoring, to establish trust between remote and potentially mutually unknown participants.

There exist proposals inside and outside academia (cf. Section Section 2); however, only IDS and GAIA-X currently provide the necessary level of detail in their documentation, allowing a detailed analysis. To this end, we limit our analysis to these proposals. Specifically, we analyze the available technical documentation and reference architecture for their implementation of adequate security and sovereignty measures. Primarily, we identify a lack of technical means to facilitate dependable security guarantees and establish strong participant trust. The current ecosystem initiatives can only partly address the security and trust requirements with their frail certification-based approaches.

Attacker Model. Guiding our position that data ecosystems require stronger data protection mechanisms, we apply the notion of a malicious-but-cautions attacker [83]. Specifically, the malicious-but-cautious attacker can misbehave in all possible ways but aims not to leave any verifiable evidence of its misbehavior [83]. Compared to an honest-but-curious (or semi-honest) attacker, this definition includes explicitly local deviation from protocols unless they are verifiable by externals. With data ecosystems exchanging data within established legal contracts, we argue that participants aim to avoid being sued for their misbehavior, and, hence, have incentives not to leave any evidence. To this end, a malicious-but-cautions attacker reflects the typical power and incentives of data ecosystem participants who source, process and utilize somebody else’s data.

Data Security. Current notions of data security include security at-rest, in-transit, and in-use [84]. At-rest security and in-transit security are considered solved problems in data ecosystems as they can use widely available building blocks such as storage encryption and transport layer security (TLS), respectively [4]. Contrarily, in-use data security targets data at the moment of processing, e.g., when the decrypted data is loaded into memory, and is more difficult to ensure and implement. Technical or cryptographic measures to protect data by providing in-use security include, for instance, hardware-assisted security or homomorphic encryption [77][85]. However, despite these measures, today’s data ecosystems build their guarantees regarding data in-use security upon remote participants’ honesty to enforce certain rights on shared data. Unfortunately, incentives to evade enforcement clearly exist with monetary compensation handled as part of data exchange and transfers entrusted for a specific purpose.

Versatility and Cost. A central argument of recent initiatives beyond improved data sovereignty is their versatility regarding data types and participants, as well as a reasonably low implementation cost. To this end, there are a few restrictions and trade-offs to consider when implementing dependable guarantees. First, they try remaining agnostic regarding the data type and format, as long as it can be automatically exchanged [5]. Hence, data protection mechanisms should also be agnostic of the data type and must reflect different options for data usage, depending on its type. Second, they try to keep entry barriers low and, among others, explicitly target participants who have limited (computational) resources or economically cannot afford certified and trained IT professionals. To this end, the overhead of cryptographic means or the need for special hardware should be limited. Overall, mechanisms for dependable guarantees should reflect these efforts by maintaining versatility at reasonable costs.

Having established the need for considering inside attackers across different notions of data security, including data in-use, while maintaining the versatility of data ecosystems, we argue that the following questions are critical to the adoption of data ecosystem initiatives in data-sensitive domains:

• I1: How can data owners trust remote infrastructure to enforce their granted rights once data has been shared?

• I2: How can data owners track their data in a trusted way if processed by remote facilities?

• I3: How can participants with little resources maintain sovereignty without requiring them to host their own infrastructure?

In the following, we elaborate on these high-level design questions regarding strong data sovereignty when implemented in practice.

I1: Trust in Remote Rights Enforcement. A first cornerstone of end-to-end data sovereignty is the guaranteed enforcement of digital rights on remote systems, i.e., usage control. However, suppose a privileged user on the consuming side, e.g., a system administrator, copies exchanged data without leaving traces in audit-relevant logging systems. This unintended behavior renders usage control enforcement ineffective. While we anticipate that such an action would violate negotiated terms, the data owner depends on fortunate coincidence to notice malicious behavior retrospectively. Consequently, we argue that data owners will refrain from using data ecosystems in their current form to share sensitive data. With such datasets covering manufacturing plans [17], the identity of suppliers [61], or privacy-sensitive health records [62] the lack of enforcement guarantees severely limits the kind of data exchangeable. Hence, such scenarios require stronger data sovereignty guarantees than the currently envisioned (weak) organizational measures.

Partly addressing this issue, IDS can utilize trusted platform modules (TPMs) as a trust anchor on remote systems [4]. However, merely providing verification of the running software, but essentially lacking memory encryption, TPMs still contribute little to effective protection against malicious-but-cautious attackers.

I2: Trusted Data Usage Reporting. Besides effective usage control, usage transparency is a second cornerstone to strong data sovereignty and essential to increase the participation of data owners. To this end, data owners who grant permissive access to their data shall still be able to track the usages of their data in remote systems transparently. Within IDS, a clearing house entity is designated to address part of this problem by enabling billing-relevant usage logging [4]. However, similarly to I1, IDS currently lacks a technically or cryptographically enforced guarantee that data usage must be logged. Hence, data users can easily circumvent the implemented logging features of today’s data ecosystems and thereby exceed granted usage terms without being caught, such as evading downstream payments for data usage.

I3: Sovereign Participation without Own Infrastructure. A third cornerstone of strong data sovereignty is the free choice of data owners with whom to exchange data under which conditions. Within the currently proposed architecture (cf. Figure Figure 1), data owners entirely rely on and trust data providers to serve their data within the ecosystem. However, if both roles are distributed between separate entities, similar trust issues as between the providing and consuming parties also apply here. Specifically, the owner needs to trust the provider to serve the agreed policies and not misuse data locally. Moreover, usage reporting systems must not assume the provider to be trusted in this case. Hence, the providing side of a data exchange requires the same measures to implement reliable trust as the consumer side.

Takeaway. Today’s data ecosystems only provide data protection via organizational means, such that they lack protection against malicious-but-cautious inside attackers on remote systems. At the same time, monetary data usage compensation and usage restrictions create incentives to evade enforcement mechanisms. Currently, these shortcomings limit the applicability of data ecosystems to share sensitive datasets irrespective of the domain or use case, and thus, need a remedy.

Toward Dependable Guarantees on Security, Sovereignty, and Trust

The current data ecosystem initiatives strive to seamlessly interconnect businesses and facilitate the automation of valuable data exchanges. However, in the last section, we identified severe open issues (I1–I3) that impede each participant’s data sovereignty in situations where organizational trust mechanisms, such as required certification prior to admission to the ecosystem, are insufficient. Given the competitive advantage a participant can gain by acting in a malicious-but-cautious manner, these open issues only become more pressing. Hence, with the data sovereignty of their participants in mind, data ecosystems must deploy additional means to allow them to establish trust in that new market.

In this paper, we argue that only technical means providing strong cryptographic guarantees are suitable to reach the goal of trustworthy and dependable data ecosystems that retain participants’ data sovereignty in the presence of inside attackers. To this end, we now discuss how available building blocks can be integrated into data ecosystems to address each of the open issues I1–I3 while maintaining versatility and considering implementation costs.

Trusted Remote Policy Enforcement (I1)

The foundation of strong data sovereignty in data ecosystems is providing data owners with an assurance that the data ecosystem will enforce terms and conditions on their behalf. Although today’s data ecosystems lack trustworthy remote enforcement of data usage terms (I1), promising building blocks for addressing this issue are already available and used in other contexts. Examples of related building blocks are distributed usage control, trusted execution environments, and different cryptographic schemes. In the following, we discuss these building blocks, their application areas, and their relation to data ecosystems.

Distributed usage control [86][87][88][89][90][91] is an established field of research that focuses on modeling and technically enforcing usage terms, so-called policies for data usage. Data ecosystems have already adopted the notion of policies in their organizational architecture [4][92]. To this end, formulating and enforcing policies in providing and consuming connectors, while not trivial, mostly is a design and engineering challenge and basic implementations are available [93]. We expect a reasonably low cost for these mechanisms, and they only reduce versatility by limiting the data usage to applications or environments that can handle policy enforcement (e.g., via Windows group policies). However, enforcing these policies proves difficult as soon as the data owner cannot trust a data user and cannot directly observe the misconduct of a data user or the consequences thereof [94]. Hilty and Pretschner [87] hence propose to provide data owners with evidence of policy enforcement and restrict possible computations. Both approaches are hard to realize within a data ecosystem as they require some technical trust anchors on remote systems. Specifically, data ecosystems currently do not offer such trust anchors as the data user gains full control over the exchanged data once it has been obtained from the data owner. This situation is insufficient when considering, for instance, a malicious-but-cautious adversary who does not provide a trustworthy environment for storing or processing the exchanged data.

Hardware-based Trusted Execution Environments (TEEs), such as Intel SGX, AMD SEV-SNP, or ARM TrustZone, are promising candidates for closing this gap in the future [95]. The goal of TEEs is to provide a trustworthy computing environment that can be established even on untrusted remote infrastructure. To this end, a TEE provides an isolated (i.e., memory-encrypted) environment for running applications with the ability to verify the integrity of the executed program code remotely. A CPU-embedded cryptographic key provides the required trust anchor that allows the data owner to verify correct execution independently of the remote host’s operating system [95]. Recent TEEs, such as AMD SEV-SNP allow protecting complete virtual machines (VMs) with reasonably low overhead [96]. Compared to earlier TEEs, such as Intel SGX, VMs even enable trusted graphical applications, such that they maintain versatility if applied within data ecosystems. Consequently, TEEs can help trustworthy remote execution by hiding the program’s execution state and hardening it against hampering.

Implementing policy enforcement and data processing inside such environments has the potential to resolve the trust issues data ecosystems are currently facing. However, TEE technology is an active field of research, and current implementations still experience security issues [97]. For example, today’s TEE implementations are prone to side-channel attacks that allow for limited data extraction [98]. Countermeasures such as oblivious RAM [99] are being investigated to fix these vulnerabilities, and we expect that future enclave designs will provide further remedies against other technical issues as they are being discovered. Hence, TEEs are a promising building block for improving data sovereignty in data ecosystems via technically enforceable data policies. However, further research into hardening TEEs against unintended security breaches is required to improve their applicability to data ecosystems. In fact, in a related context, a first work [77] demonstrates the applicability of TEEs in a trusted data-sharing setting.

We thus call for the established initiatives and researchers to further investigate the utility of TEE technology for data ecosystems to reliably address the lack of trustworthy and technically backed policy enforcement.

Verifiable Data Tracking (I2)

Besides policy enforcement, establishing transparency in data usage is equally important to gain data owners’ trust. For instance, a data owner might consider granting generous accessibility to their data but require proper attribution by any data user. In such a case, the data owner would profit from technically guaranteed notifications whenever a data user accessed the data.

Currently, IDS implements a clearing house instance, which can log data usage if mandated in a policy, making it transparent to data owners [4]. However, data users have neither a strict technical constraint to log data usage, nor can the system enforce it by some means. Consequently, IDS cannot currently provide trusted monitoring unless data usage can be observed externally. Hence, the current clearing house instance does not solve the problem of verifiable data tracking (I2).

Instead, technical or cryptographic means would help to incentivize logging. To this end, we consider transparency logging, data-flow tracking, and distributed ledger technology promising for establishing verifiable data tracking in data ecosystems. For instance, certificate transparency logging allows modern web browsers to reject digital certificates that are not tracked in a public log for auditors to verify [83]. It has shown to be a scalable and cost-effective tool for public verifiability in the context of PKI. A similar approach might improve data usage transparency as well [100]. Namely, cryptographically tying the decryption of exchanged data or the transfer of results to a publicly verifiable log entry would force data users to log their actions accurately. As long as log entries are small, only a few distributed log instances could handle the workload of millions of transactions, such as shown by the PKI example [101]. Similar approaches are also being researched in the field of verifiable computing [102][103] and data ecosystems could profit by utilizing corresponding building blocks.

Besides logging, related work also proposes data flow tracking [104] and data fingerprinting [105] to allow for identifying the source of identified data breaches after the fact. However, the cryptographic data fingerprints required to apply these techniques necessitate knowledge of the exact data representation and a sufficient tolerance for minor statistical noise in the monitored data [105]. Thereby, these methods are limited in their versatility, which depends on the concrete data to be shared. Unfortunately, these fingerprints typically cannot survive intermediate processing steps [105], rendering them inapplicable in some situations. Hence, more research on resilient data flow tracking or fingerprinting techniques is required to determine and improve their applicability in the context of data ecosystems.

Finally, distributed ledger technology has emerged in recent years with the explicit goal of facilitating digital interactions among participants who do not fully trust each other. While Bitcoin started by establishing a decentralized and publicly accessible digital currency based on a blockchain [106], it spawned more versatile distributed ledgers for any information using smart contracts [107]. Ultimately, business-focused ledger systems emerged, such as Hyperledger Fabric or Quorum. These architectures can facilitate the event-logging within data ecosystems and provide a medium for the automated billing of data accesses.

To avoid additional privacy or data confidentiality problems, such transparency mechanisms need to take privacy into account, e.g., by encrypting log entries [108]. Overall, technical building blocks for verifiable data tracking are already available. However, they still need to be tailored to the specific verifiable data tracking requirements for utilization in data ecosystems regarding performance, scalability, flexibility, and privacy.

Integration of Resource-Constrained Participants (I3)

With the separation between the data provider and data owner, data ecosystems also address scenarios that involve particularly resource-constrained or especially privacy-aware data owners who are unable or unwilling to run the complete infrastructure themselves. However, infrastructure control is the foundation of self-sovereign participation in distributed environments [4]. Hence, this approach is not viable for resource-constrained participants. Such participants could be, for instance, small to mid-sized enterprises (SMEs) in a supply chain context, which have no technical expertise to provide the infrastructure to participate in a data ecosystem. In this case, their customers may be capable of assuming the role of a data provider collecting data from their contracted SMEs and offering that data on their behalf within the ecosystem. For instance, large automotive manufacturers can assume the role of a data provider on behalf of their, typically numerous, suppliers [17]. In this case, however, data owners lose their sovereignty and depend on trust in their customers. Thus, appropriate dependable guarantees for such situations are desirable.

A scenario that would assure data owners that their data is treated as intended would be considering the data provider as a different party than the data owner; however, current ecosystem initiatives do not rigorously satisfy this demand [4]. Under this assumption, however, one could implement the same measures discussed in Section Section 4.1 also on the provider side, i.e., realize a trusted data provider. Moreover, concerning usage transparency, this scenario requires logs, as discussed in Section Section 4.2, to be accessible with no own infrastructure. Hence, not only the consumer-side aspect of logging must be trusted, but also the instance that provides logging on behalf of data owners.

Resource constraints of SMEs not only affect computational resources, such as for hosting a connector acting as a data provider or data consumer. Another constraint can be human resources or their required training and level of certification, e.g., to obtain ISO 27001 certification [46]. To this end, dependable guarantees might be able to render the need for such certification unnecessary. Given that, for instance, TEEs are widely available on modern CPUs by default, we argue that they can be a viable alternative to certification.

Summary

Cryptographic building blocks that have been successfully applied in the past are also promising to address the core issues (I1–I3) currently impeding the data sovereignty of data owners in today’s data ecosystems. For instance, TEEs have the potential to provide the currently missing trust anchor during remote processing (I1). Similarly, concepts currently applied in the context of certificate transparency logging or distributed ledger technology may help satisfy the requirement for verifiable tracking in data ecosystems (I2) once they are adapted to the scalability demands of envisioned deployments. Finally, these measures can also potentially be applied when data providers operate on behalf of the original data owner to incorporate resource-constrained participants in the process (I3).

Exemplary Case Studies Highlight the Need for Dependable Guarantees

In the following, we highlight the findings of our analysis in the context of three real-world applications concerning personal data (), economic data (), and governmental data (). Despite their diverse origin, each application accentuates our proclaimed need for dependable security measures. To this end, we give an overview of three unique use cases, namely data in health research (Section Section 5.1), supply chains (Section Section 5.2), and smart cities (Section Section 5.3). All these use cases have already been approached using data ecosystems. We then compare their unique requirements concerning data security and sovereignty in Table Table 1 and discuss how each of them relates to the core issues that we identified in Section Section 4.

Sharing Health Data for Research

A frequent application of data ecosystems is to share health data for research purposes. In the following, we discuss the example of the UK Biobank (UKB) [109] as one data ecosystem that is already established. The UKB stores and processes personal information of significant sensitivity, and has clear governance principles concerning data security. The UKB is a large-scale model cohort study and biomedical database that provides comprehensive data access for health-related research in the public interest. It contains detailed health and genetic information of more than 500000 participants aged between 40 and 69, enabling research based on this unique data set. Between 2006 and 2010, participants gave informed consent for long-term health monitoring, genotyping, and linkage to medical records. They provided blood, urine, and saliva samples for future analysis [110] and detailed information about themselves in 22 assessment centers throughout the UK.

Since 2012, researchers can apply to use the UKB for their studies, and the UKB is openly accessible to any bona fide researcher who wishes to use it to conduct health-related research for the benefit of the public. More than 80000 research groups from industry and academia worldwide can access the data ecosystem or have applied for access. The development of this resource has involved extensive consultation, input from scientific, managerial, legal, and ethical partners, and centralized processes on an industrial scale [111]. The UKB database is expected to grow to 15 petabytes over the next five years [112]. However, while the data infrastructure’s impact on the environment is widely recognized, data sovereignty is a topic yet to be discussed [113].

Still, current workflows to secure data when shared include an ethical and governance framework and access procedures for the scientific community, the general public, and other stakeholders [114]. Precisely, the UKB removes personally identifiable information before sharing data with others for research purposes. Data users must follow a reviewed application process, ensuring research legitimacy using the data in public interest [114]. In addition, data users must sign a legal declaration not to try identifying individuals. Here, reidentification is a major problem. For instance, predicate singling out attacks can allow to re-identify individuals in pseudonymized datasets with few traits, such as a rough estimation of location and age [115]. Many other cohort studies have followed UKB, using the same methodology (e.g., “All of us cohort” [116]). As such, the UKB is a prime example of the importance of sovereignty in data ecosystems.

Moreover, the UKB has attempted to address access to data in a practical and non-bureaucratic manner for researchers. The UKB has implemented a fair, transparent, and efficient online access process [117]. The aim is to ensure that the resource and its access arrangements are widely communicated to the scientific community and to provide open access to its data and samples for health-related research in the public interest. Only if the proposed research is in the public interest and the required data are or will be available will requests for data be approved. Additionally, researchers will only be provided with de-identified data and must sign a material transfer agreement. In this agreement, they confirm not to attempt to identify participants, to keep the data secure, and to use it only for the approved research. However, UKB does not employ measures that would render, e.g., participant identification, impossible, and past research has shown that solely relying on the concept of $k$-anonymity is insufficient [118][119]. Thus, despite the need for technical concepts, currently, there are no technical limitations that prohibit copying, sharing, or using data for other than approved purposes.

The UKB’s robust data protection framework sets out the fundamental principles, rights, and obligations for processing personal data [114]. As a responsible custodian of participant data and samples, UKB is legally obligated to ensure that they are stored, retrieved, and used securely with appropriate technical and organizational measures [120]. To this end, UKB must also take reasonable steps to protect any data or samples it shares with others. Thus, researchers who access UKB data must implement security measures to ensure that the data is processed and used securely and compliant. These measures should restrict access to authorized users and protect against unauthorized access by internal or external parties [109]. However, UKB has no means to verify or restrict data usage once shared, nor are there viable technical means, e.g., if patients want to withdraw given consent. Most UKB data are available for download, i.e., without control. Only enormous datasets (e.g., whole genome sequencing) are accessible through the research platform itself only, enabling means to assess data usage [121].

Participants can withdraw their consent or exercise a right to erasure at any point in time [122]. The participant withdrawal form, however, only covers future data usage. Here, UKB argues that researchers only receive a de-identified copy of data, such that data used in ongoing and completed studies are not subject to the GDPR’s right to erasure [122]. However, it remains unclear whether the de-identification process is dependable, as research on its reliability is explicitly forbidden by the data usage agreement. To this end, mechanisms for privacy-preserving tracing of data usage (I2) could at least yield a list of pointers to studies relying on data for which consent shall be withdrawn.

Another often-faced criticism is that the UKB does not generally provide feedback on individual-level results derived from data obtained during assessments [109] to respect the informed consent given by participants, i.e., lacks privacy-preserving data provenance and data lineage mechanisms that would allow selective feedback channels upon the patients wish. Solving this problem, e.g., by giving participants a more active role in such a data ecosystem would automatically allow feedback. Currently, participants receive a summary of measures at the end of each assessment visit. They are encouraged to see a doctor if their results are outside the normal range. Direct feedback creates an incentive for participation, eventually increasing the database size. A broader data basis would allow for more input data e.g., to classifiers trained on that database, but also solve the potential genetic bias UKB might face, as UKB primarily focuses on upper-class white individuals. In the long term, this would enable fairer and more accurate models.

At the same time, stricter guarantees on how the covered personal data is shared and can be analyzed increase the sovereignty of participants and, hence, might reduce the threshold for participation or even enable future studies to utilize health data on a broad scale. Still, establishing the UKB provided valuable insights into the essential components needed to create large-scale studies, including efficient governance, centralized infrastructure, extensive research data, and widespread public support [123]. As such, UKB shows how broad data access in a permissive, voluntary setting and with explicit patient consent enables medical research.

Overall, the UKB highlights the specific need for personal data in medical contexts, including consent and traceability. The UKB consent scheme, i.e., giving broad consent, on the one hand, enables data availability for research purposes. On the other hand, it limits the data basis to those patients willing to give such broad consent despite considerable privacy impacts and the current lack of feedback options or the personal benefit of participation. Concerning our analysis, we argue that traceability (I2) is inherently lacking, and participation on the patient level (I3) is currently limited to giving consent once without a continual sovereign decision beyond the capability to revoke that consent. Patients then entrust UKB with handling their data accordingly and UKB-authorized researchers with not evading differential privacy applied to shared datasets. Hence, dependable guarantees concerning the remote enforcement of granted access and usage rights (I1) is relevant as well.

Supply-Chain Data Management in Digital Production

Today’s digitized production and globalized supply chains pose another stimulating use case for which data ecosystems are being discussed. In fact, IDS has origins in this domain as several requirements and architectural components originate in a preceding project named industrial data space [124]. The key motivation for data protection here is protecting intellectual property and maintaining competitive advantages instead of personal data protection [125][126]. With physically distributed and organizationally separated suppliers and consumers, supply chain applications match the scenario of federated data ecosystems [61]. Moreover, data exchange and the ability to authentically track and trace goods along supply chains today is considered a cornerstone of modern industry [17]. Relevant data in this context includes, but is not limited to, operations, performance optimization, billing, and logistics [17]. For instance, financial data, trade secrets, or construction plans are subject to intellectual property claims. Hence, data security, especially authenticity and confidentiality, is essential to secure modern supply chains to prevent unauthorized access, data breaches, and cyber-attacks.

The data exchange process in supply chains involves multiple parties, such as suppliers, manufacturers, distributors, retailers, and customers. At the same time, relationships between these parties can be short-lived and not necessarily built upon prior mutual trust [17]. Furthermore, supply chains are inherently intransparent. For instance, involved parties typically only know their direct trade partners, i.e., whom they buy parts from and to whom they sell their goods to, as suppliers and prices are a well-kept secret [17]. Still, specific information needs trustworthy mechanisms to propagate along supply chains, such as resource and environmental certificates [127].

Relationships within supply chains can also build on general distrust, such as between direct competitors that share common production facilities. In this context, companies are reluctant to share data and prefer to protect their intellectual property, also coined as “company privacy” [126]. Proposed data ecosystems, including IDS [4], currently try to solve this problem. However, the concerns regarding the organizational security approach fully apply here as the current design requires companies to entrust competitors with the enforcement of data access terms to their own disadvantage (cf. Issue I1).

Without standardized data ecosystems, data exchange happens via various methods, such as email and customer relationship or supply chain management systems. Initiatives, such as CATENA-X, prepare to supersede these methods [43]. In addition to the above-mentioned problems, these initiatives face some specific additional challenges: For instance, ownership of data is already a complicated endeavor as it is left unclear by law [15]. However, within supply chains, it must also be trackable who owns derivative data that builds on a prior data exchange [128]. Such requirements are not limited to data ownership. Authenticity and authorization must also cover derivate data, e.g., the German supply chain law aims to enforce human rights in global supply chains and imposes significant fines if necessary certificates are missing [129]. Hence, companies are interested that data passed along supply chains remains authentic.

In conclusion, data security is critical in supply chain applications that involve exchanging sensitive and confidential information. Efforts centering around current initiatives (cf. Section Section 2) reflect the need to simplify data logistics within supply chains and also to secure them accordingly. Ensuring the security of data exchanged in supply chains protects data’s confidentiality, availability, and authenticity. To this end, we emphasize that trust in remote rights enforcement (I1) and trusted traceability (I2) require a solution for data ecosystems to be viable in this context. Given that companies of different sizes, including small and midsized enterprises, are often an essential part of supply chains, we argue that their sovereign participation (I3) must also be considered.

Smart City Applications

Besides personal and economic data, governmental data poses another application area for data ecosystems. Several unique challenges require a solution to implement data sovereignty in the context of governmental data and governmental data use cases often fit the scenario of data ecosystems. Applications range from open data as a relatively permissive scenario that, however, still can have traceability and revocation requirements [31], to rather sensitive use cases, such as demographic data on an individual level [31]. At the same time, especially to combat climate change and deal with the change in demographics, the analysis of rich data sources promises the potential for significant insights [130]. In the following, we emphasize two use cases of data ecosystems centering around smart city applications, which despite their public origin face several severe challenges in implementing data sovereignty. To underline that dependable guarantees are not only a problem of sectors involving personal or economic data, we highlight two of these directions, namely smart grids and smart public transport, in more detail.

Generally, Kirimtat et al. [131] characterize smart cities as consisting of several themes, including, for instance, smart heating, smart transport, and smart grids. We refer to prior work for a more detailed analysis [131] but emphasize that all these applications build upon derivates from personal data, e.g., collected at municipal utilities, public transport, or in private homes. Often, the data itself was not collected for applications in smart cities in the first place but was intended for other purposes, such as billing or operational monitoring. Such secondary use then poses privacy and data sovereignty questions. For instance, local electrical power or district heating grids gain significant relevance and are in the process of digitization [132]. Given that data collection happens at the level of households, i.e., individuals, data sovereignty becomes relevant here as well: Existing grid meters, which first serve billing purposes, now also provide presence detection, i.e., are a proxy for personal data [133].

Mapping such a use case to the scenario that we emphasized in Section Section 2 introduces a few unique challenges: The data provider often is the local grid operator. However, whether the data owner should also be the grid operator or the data subject, i.e., the residents of the household being monitored, remains unclear. Customers to the grid operator should ideally be capable of specifying with whom and under what granularity they want to share data. However, grid operators are also a stakeholder in this decision. As the central goal is to gain more insights into the grid, allowing better utilization, service delivery, and eventually a reduction of costs, grid operators have the incentive to pursue integration. Solving these problems with dependable guarantees concerning the (sensitive) data provided by residents might resolve some of their concerns against rolling out monitoring systems on a broad scale [134].

Another frequent use case within smart cities covers public transport systems [135]. These systems heavily rely on collecting, processing, and exchanging vast amounts of data, frequently including personal information about passengers, such as their travel patterns, payment details, and geolocation data, i.e., data that passengers aim to keep under their control [135]. At the same time, public transport systems are often a consortium of different actors, e.g., partitioned by means of transportation [136] and affected by mutual trust issues (cf. I1). These actors already exchange data but keep passengers out of the loop, who hence cannot control or audit the usage of their data (cf. I2). Additionally, using sensors and other data collection technologies can raise concerns about data sovereignty, particularly if this data is being shared with third-party providers or used for commercial purposes without passenger consent.

Dependable guarantees to solve the discussed issues with governmental data are manifold. For instance, grid meter readings are reasonably small to be protected by cryptographic means, such as HE, and we anticipate most processing to happen automatically, such that an implementation of dependable guarantees would not limit the versatility for that use case. TEEs, on the other hand, could help consortia of public transport providers to reduce their interdependencies when working with personal data. With their general availability on (at least) server hardware (cf. Section Section 4), limited overhead can be expected. Efforts toward embedding TEEs in mobile devices, e.g., via ARM TrustZone, might complement these directions and enable dependable guarantees even for shared ticket machines.

In conclusion, implementing data ecosystems in governmental applications, such as power grids and public transport, can provide several benefits, including increased efficiency, cost reduction, improved service delivery, and sustainability. At the same time, re-purposing already collected data, such as in the power grid, raises new data sovereignty requirements, which a data ecosystem must handle. Concerning the identified issues, we deem the sovereign integration of smart grid customers and public transport passengers an important issue (cf. I3), but we further note that trusted enforcement (I1) and traceability (I2) also apply here.

Summary

Table 1 summarizes the key findings from each presented use case. While incentives for applying data ecosystems to the introduced use cases and the key requirements regarding data security and sovereignty are diverse, our identified issues are relevant to all of them. In Section Section 4, we already introduced several building blocks to mitigate I1–I3. Given the specific requirements e.g., regarding data volume and computational effort, research on personal health data might rather implement a performant technical solution to I1, such as via TEEs, whereas data in the context of smart grids, such as meter readings, can be aggregated via cryptographic means. Similarly, the design of traceability (I2) and participation (I3) building blocks depend on the use case, and hence, need a tailored solution. In the following, we related the findings from our use case description to the issues we identified in this paper and set out future directions for research to mitigate this situation.

Systematically Mapping Security Features in Federated Data Ecosystems

In this paper, we have detailed our position that current data ecosystems are not well-prepared to address the needs of sovereignty in federated environments, such as those targeted by the discussed data ecosystems. At the same time, such dependable guarantees would help increase data ecosystems’ applicability to common use cases, as we discussed in Section Section 5. We now underpin our position by systematically mapping academic works in the context of data ecosystems concerning the issues I1 to I3.

We follow the guidelines of Petersen et al. [137] to conduct a systematic mapping study on the security assumptions and technical building blocks for security, sovereignty, and trust employed by academia. Compared to an in-depth literature review, a mapping study employs broader inclusion criteria and intends to map security considerations rather than synthesize study results. For a more general overview of data ecosystems, we refer to the study from Oliveira et al. [49], who have mapped related work on data ecosystems in a general sense, but did not review any security aspects.

To quantify the proclaimed lack of strong security approaches (cf. Section Section 3), we assess prior work in the context of federated data ecosystems and data markets concerning their contributions toward secure and trustworthy data exchange and processing. We base our analysis on the Issues I1 (trusted enforcement), I2 (usage transparency) and I3 (sovereign participation) that we have established in Section Section 3. Dependable guarantees for these issues exist, as outlined in Section Section 4, but it remains unclear whether academia implements any of them. Hence, we study the adoption of those dependable guarantees in the following and also map academia’s notion of security and trust in data ecosystems in a more general sense based on the following research questions:

1. To which end does prior work related to data ecosystems consider security and trust issues generally?

2. What kind of security contributions are made?

3. Which building block, technology, or concept provides dependable security features, if any?

These research questions provide an orthogonal view on the issues we identified in Section Section 3: While I1 to I3 each highlight needed security features, RQ1 to RQ3 focus on different levels of security considerations in related work, i.e., RQ1 considers the general notion of security, RQ2 focuses on the specific security features, and RQ3 on the technical realization of these features. This gradation allows us to differentiate between different levels of technical readiness regarding the stated issues. To answer these research questions, we first describe the methodology of our systematic mapping study with its methodology regarding the inclusion and exclusion of related work, before discussing RQ1–RQ3 in detail.

Methodology and Research Corpus. Focusing on a broad coverage with our study, we include works that contain at least one of the terms “data ecosystem”, “data sovereignty”, “data market” or “data marketplace” in their title, abstract, or keywords. While the latter two search terms are not directly related to data ecosystems, we consider them closely related to the idea of what has more recently been coined as a data ecosystem. Thus, these works might contribute dependable guarantees in a scenario applicable to our study. We query Scopus and Web of Science for results matching either of our keywords in June 2023. Overall, our search yields 2993 papers containing at least one of our search terms.

From the query result set, we excluded studies that match at least one of the following exclusion criteria (in that order, Table Table 2b details each criterium):

1. The work is duplicated (based on title and authors) or redundant (e.g., full conference proceedings).

2. The work is not written in English language.

3. The work is not peer-reviewed (e.g., keynote abstracts, editorials, presentation slides, etc.).

4. The work does not mention at least one of the keywords listed in Table Table 2b in its title, abstract, or keywords.

5. The study does not consider security or trust in the context of data ecosystems.

For EC1 to EC3, we rely on the output from Web of Science and Scopus to exclude studies automatically. EC4 to EC5 help to narrow the scope to papers relevant to our research questions. To this end, EC4 filters studies based on additional keywords relevant to our research questions. We validated the chosen set of keywords by randomly selecting a subset of 1/4 of the studies excluded by EC4 where we manually reviewed abstracts. This step did not reveal any additional relevant studies that would have been falsely excluded.

EC5 was manually assessed by a single author, based on title, abstract, and keywords, and if in doubt, also based on the full text. Here, we do not assess works qualitatively, but categorize them based on their contribution and their applicability to data ecosystems. We argue that this categorization is bias-free, but want to briefly cover the most frequent causes of exclusions to support reproducibility. Specifically, we exclude works that, despite mentioning at least one of the chosen keywords, do not contribute to the scope of our review. Frequent excluded topics concern the governance and (structural) organization of data ecosystems or markets (64 articles), ethics and legal concepts related to data sovereignty (57 articles), or pricing models for private data and economic considerations of data sharing (41). Additionally, 20 articles focus on the data sovereignty of indigenous people. We argue that a central aspect of data ecosystems is to differentiate between data owners and data users, and thus exclude works that do not differentiate between these roles. Besides that, EC5 does not exclude architectures not considering a platform for initiation of data exchanges.

RQ1: To which end does prior work related to data ecosystems consider security and trust issues generally? Considering the exclusion criteria EC4 and EC5 gives a first quantitative impression of the role security-relevant research plays in the context of data ecosystems. Out of the 1958 peer-reviewed studies after deduplication, 773 match at least one of the keywords specified in Table Table 2b. However, our manual review of these 773 studies to filter for EC5 shows that a relatively large fraction of these works (66 %), despite mentioning a keyword, do not further focus on a contribution to enhance data ecosystem security. A frequent storyline in these excluded studies is that federated platforms enhance security, privacy, or trust through their architecture. Moreover, studies mention the advancements in the context of blockchain as a (valid) motivation to research data platforms. Another focal point of investigation are works that outline requirements, challenges, and future research directions, most often quite generally and not specifically geared toward the scope of our study. Overall, after filtering EC5, we consider 262 studies with a title or abstract that claims to make a relevant contribution relating to data platforms, such as federated data ecosystems as defined in Section Section 2.

Figure Figure 2 shows the distribution of the included studies based on their publication year and the geographic location of the first author’s first affiliation. The topics have gained momentum from 2017 to 2018, with a significant increase and a relatively stable publication rate since then. The introduction of stricter privacy legislation around that time, e.g., GDPR, likely contributed to this increase. The geographic distribution shows that research is conducted worldwide, although with an emphasis on EU member states, as 50 % of studies originate there. Further, the authors that have contributed to the included studies constitute a diverse group: 889 unique authors have on average authored 1.16 of the 262 considered articles. No author has published more than 6 of the included articles.

To get a first intuition of topics considered by the authors of the studies we include for our analysis, we source the list of author-provided keywords. Here, we identified four general directions, as shown in Table Table 3, to which we attribute the most frequent keywords. Figure Figure 3 shows the topical combination of these general directions. Here, we find that works centering around data ecosystems (red category) seem to consider data security and privacy more frequently (59 %) than works in the data market category (33 %), although the latter covers more works in total numbers (49 vs. 83). However, given that the most frequent keywords shown in Table Table 3 remain at a rather superficial level, we instead rely on manual assessment to investigate contributions, as detailed in the following.
